Passive network monitoring with arpwatch

arpwatch is a lightweight network monitoring tool used to passively observe ARP (Address Resolution Protocol) packets on a local network. It was developed to to track the mapping between IP and MAC address. A change in this mapping is generally an indicator of a MAC spoofing or arp cache poisoning attack. In this situation, arpwatch can send an email alert to administrators.

The tool can also be used to perform passive network monitoring. It allows to list devices connected on the local network, like nmap, but without sending a single packet, only listening on received arp packets…

Installation

Arpwatch is available in most distributions, so installation is easy:

sudo apt install arpwatch

However there is however a catch: arpwatch must be manually enabled for each network interface:

sudo systemctl enable arpwatch@<interface>

For example:

sudo systemctl enable arpwatch@enp0s1

Then (re)start the daemon:

sudo systemctl restart arpwatch.service

Monitor network devices

After a few seconds, arpwatch will populate the file /var/lib/arpwatch/<interface>.dat with discovered devices.

For example:

sudo cat /var/lib/arpwatch/enp0s1.dat

2c:fa:a2:b3:84:0b	10.67.42.2	1777470939		enp0s1
48:45:e6:b2:79:7b	10.67.42.194	1777470939		enp0s1
2c:fa:a2:a5:c0:70	10.67.42.5	1777381241		enp0s1
e4:e7:49:5b:dc:c9	10.67.42.186	1777462917		enp0s1

In this file, the 3rd column is the timestamp.
